Asus PRIME B660M-A WIFI D4 Intel B660 LGA 1700 micro ATX

Asus PRIME B660M-A WIFI D4 Intel B660 LGA 1700 micro ATX

Availability: Delivery to the store takes 3 - 7 business days.
ID: 102172
Product Code: 90MB1AE0-M1EAY0
Barcode 4711081518105
111.85€
(Ex Tax: 90.20€)
Payment options

Delivery options

omniva  venipak



Description
Description
Compatible processor seriesIntel® Core™ i3
Processor manufacturerIntel
Processor socketLGA 1700
Maximum number of SMP processors1
Number of displays supported3
Motherboard form factormicro ATX
Audio output channels7.1 channels
Motherboard chipset familyIntel
Motherboard chipsetIntel B660
Audio chipRealtek ALC897
Windows operating systems supportedWindows 11 x64
Supported memory clock speeds2133
Maximum internal memory128 GB
Unbuffered memoryYes
Supported memory typesDDR4-SDRAM
Memory slots typeDIMM
Memory channelsDual-channel
Number of memory slots4
ECC сompatibilityNon-ECC
Height60 mm
Width244 mm
Depth244 mm
BluetoothYes
Wi-Fi standardsWi-Fi 5 (802.11ac)
Ethernet LANYes
Wi-FiYes
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Bluetooth version5.2
Ethernet interface typeGigabit Ethernet
Number of SATA III connectors4
USB 2.0 connectors3
ATX Power connector (24-pin)Yes
S/PDIF out connectorYes
Front panel audio connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors3
RGB LED pin headerYes
CPU fan connectorYes
Number of COM connectors1
12V power connectorYes
EPS power connector (8-pin)Yes
Number of chassis fan connectors2
BIOS typeUEFI AMI
Drivers includedYes
Cables includedSATA
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA
DisplayPorts quantity1
DisplayPort version1.4
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity4
PS/2 ports quantity1
HDMI version2.1
Microphone inYes
Headphone outputs1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
HDMI ports quantity2
PCI Express x16 (Gen 3.x) slots2
Number of M.2 (M) slots2
PCI Express x16 (Gen 4.x) slots1
Weight819 g
Harmonized System (HS) code84733020
WarningsDo not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
