Home Computers and equipment Computer components Motherboard Asus ROG STRIX B760-F GAMING WIFI Intel B760 LGA 1700 ATX
Asus ROG STRIX B760-F GAMING WIFI Intel B760 LGA 1700 ATX

Asus ROG STRIX B760-F GAMING WIFI Intel B760 LGA 1700 ATX

Availability: Delivery to the store takes 3 - 7 business days.
ID: 102176
Product Code: 90MB1CT0-M1EAY0
Barcode 4711081974666
245.09€
(Ex Tax: 197.65€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor socketLGA 1700
Compatible processor seriesIntel® Core™ i7
Supported processor socketsLGA 1700
Processor manufacturerIntel
Maximum number of SMP processors1
On-board graphics cardNo
Parallel processing technology supportNot supported
Motherboard form factorATX
Power source typeATX
Windows operating systems supportedWindows 10
Audio output channels7.1 channels
Cooling typePassive
Motherboard chipsetIntel B760
Audio chipRealtek ALC4080
Product colourBlack
Motherboard chipset familyIntel
Supported memory clock speeds6600
Number of memory slots4
Supported memory typesDDR5-SDRAM
Memory slots typeDIMM
Maximum internal memory192 GB
ECC сompatibilityNon-ECC
Unbuffered memoryYes
Memory channelsDual-channel
Supported memory clock speed (max)7800 MHz
Depth244 mm
Width305 mm
Wi-Fi standards802.11g
Bluetooth version5.3
BluetoothYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiYes
Ethernet LANYes
Top Wi-Fi standardWi-Fi 6E (802.11ax)
ATX Power connector (24-pin)Yes
USB 2.0 connectors2
Front panel audio connectorYes
Thunderbolt headers1
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Peripheral (Molex) power connectors (4-pin)1
Number of chassis fan connectors4
12V power connectorYes
RGB LED pin headerYes
Chassis intrusion connectorYes
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
EPS power connector (8-pin)Yes
Number of SATA III connectors4
CPU fan connectorYes
Front panel connectorYes
BIOS typeUEFI AMI
Clear CMOS buttonYes
Package weight1.27 kg
Package width280 mm
Package height265 mm
Package depth71 mm
User guideYes
Cables includedSATA
RAID levels5
RAID supportYes
Supported storage drive interfacesM.2, SATA III
Supported storage drive typesHDD & SSD
Number of HDDs supported4
Number of storage drives supported7
DisplayPort version1.4
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
DisplayPorts quantity1
Microphone inYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
Headphone outputs1
HDMI ports quantity1
USB 3.2 Gen 2x2 Type-C ports quantity1
HDMI version2.1
WiFi-AP antenna jack2
Line-inYes
S/PDIF out portYes
Number of M.2 (M) slots3
PCI Express x1 (Gen 3.x) slots2
PCI Express x16 (Gen 3.x) slots1
PCI Express x16 (Gen 5.x) slots1
Back-to-BIOS buttonYes
WarningsDo not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
