Home Computers and equipment Computer components Motherboard Gigabyte B850 GAMING WIFI6 Motherboard - AMD Ryzen 9000 Series CPUs, 6+2+2 Phasen Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, GbE LAN, WIFI 6, USB 3.2 Gen 2
Gigabyte B850 GAMING WIFI6 Motherboard - AMD Ryzen 9000 Series CPUs, 6+2+2 Phasen Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, GbE LAN, WIFI 6, USB 3.2 Gen 2

GIGABYTE

Gigabyte B850 GAMING WIFI6 Motherboard - AMD Ryzen 9000 Series CPUs, 6+2+2 Phasen Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, GbE LAN, WIFI 6, USB 3.2 Gen 2

Out Of Stock
ID: 102785
Product Code: B850 GAMING WF6
Barcode 4719331866631
164.17€
(Ex Tax: 132.40€)
Payment options

Delivery options

omniva  venipak



Description
Description
Warranty period3 year(s)
Processor socketSocket AM5
Compatible processor seriesAMD Ryzen 9000 Series
Supported processor socketsSocket AM5
Processor manufacturerAMD
Parallel processing technology supportNot supported
Maximum resolution4096 x 2160 pixels
HDCPYes
DirectX version12.0
Windows operating systems supportedWindows 11 x64
Power source typeATX
Motherboard chipset familyAMD
Audio output channels7.1 channels
PC health monitoringFan
Motherboard form factorATX
Motherboard chipsetAMD B850
Audio chipRealtek ALC897
Product colourBronze
Maximum internal memory per slot64 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
ECC сompatibilityNon-ECC
Supported memory typesDDR5-SDRAM
Supported memory clock speeds8000
Unbuffered memoryYes
Maximum internal memory256 GB
Supported memory clock speed (max)8200 MHz
Height35 mm
Width305 mm
Depth244 mm
Wi-Fi standards802.11b
Wi-FiYes
Ethernet LANYes
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Ethernet interface typeGigabit Ethernet
WLAN controller modelRealtek RTL8111H
Bluetooth version5.3
BluetoothYes
EPS power connector (8-pin)Yes
Total number of SATA connectors4
Number of water pump connectors2
Number of SATA III connectors4
Peripheral (Molex) power connectors (4-pin)1
RGB LED pin headerYes
Number of CPU fan connectors2
Number of chassis fan connectors3
ATX Power connector (24-pin)Yes
Number of EPS power connectors (8-pin)1
Front panel audio connectorYes
12V power connectorYes
Serial port headers1
Number of RGB LED pin headers4
TPM connectorYes
CPU fan connectorYes
Front panel connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
USB 2.0 connectors2
BIOS typeUEFI AMI
Desktop Management Interface (DMI) version2.7
Clear CMOS jumperYes
Clear CMOS buttonYes
Package height80 mm
Package width335 mm
Package weight1.76 kg
Package depth270 mm
Bundled softwareNorton Internet Security (OEM version) LAN bandwidth management software
Screws includedYes
Batteries includedYes
Antenna includedYes
RAID levels10
Number of storage drives supported7
RAID supportYes
Number of HDDs supported4
Supported storage drive interfacesM.2, SATA III
Supported storage drive typesHDD & SSD
DisplayPort version2.1
HDMI version2.1
Headphone outputs1
WiFi-AP antenna jack2
Microphone inYes
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 2.0 ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
HDMI ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
DisplayPorts quantity1
2nd M.2 largest key size22110
2nd M.2 highest PCI Express generation4.0
3rd M.2 highest PCI Express generation4.0
3rd M.2 largest key size22110
Number of M.2 (M) slots3
PCI Express x16 (Gen 3.x) slots3
1st M.2 highest PCI Express generation5.0
1st M.2 largest key size25110
PCI Express x16 (Gen 5.x) slots1
Battery weight3 g
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Number of battery cells1
Battery typeCR2032
Lithium weight per battery0.07 g
Weight1.51 kg
Products per shipping (inner) case1 pc(s)
Country of originChina
