Asus Motherboard ROG MAXIMUS Z890 APEX s1851 4DDR5 TB4 ATX/90MB1IP0-M0EAY0

Asus Motherboard ROG MAXIMUS Z890 APEX s1851 4DDR5 TB4 ATX/90MB1IP0-M0EAY0

Delivery to the store takes 3 - 7 business days.
ID: 139906
Product Code: ROG MAXIMUS Z890 APEX
Barcode 4711387754290
760.54€
(Ex Tax: 613.34€)
Payment options

Delivery options

omniva  venipak



Specification
Description
Specification
artikuls: KBASUIIFZ890A07
svītrkods: 4711387754290
Description
SKUKBASUIIFZ890A07
Barcode4711387754290
ModelROG MAXIMUS Z890 APEX
CPU socketLGA1851
Processor familyIntel Core Ultra
Integrated CPUNo
Chipset manufacturerIntel
Chipset typeIntel Z890 Chipset
Memory typeDDR5
Number of DDR5 slots2
Memory bus frequency8800 MHz
Max memory size96
Expansion slots2 x PCIe 5.0 x16
Expansion slots2 x PCIe 4.0 x 4
Expansion slots5 x M.2
Max. number of SATA devices4
RAIDNo
Detailed data on disk/drive interfacesSupport Intel Core Ultra Processors(series 2)*M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**Intel Z890 ChipsetDIMM.2_1 slot (Key M) via ROG DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)DIMM.2_2 slot (Key M) via ROG DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)4 x SATA 6Gb/s ports* Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5.**M.2_3 & M.2_4 share bandwidth with PCIEX16(G5)_2. When M.2_3 is enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will run x4. When M.2_3 & M.2_4 are enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will disabled.
Graphics2 x Intel Thunderbolt 4 (USB Type-C) ports support DisplayPort and Thunderbolt video output*** Graphics specifications may vary depending on processor type. For updates, visit www.intel.com.**Supports up to 8K@60Hz x1 with DSC or 4K@60Hz x2, with a maximum total bandwidth of up to 23.8 Gbps or 16 Gbps/16 Gbps. For supported resolutions, see DisplayPort 2.1 specifications.*** VGA resolution support depends on processor or graphics card resolutions.
Sound cardROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080* Impedance sensing for front and rear headphone outputs Supports: jack detection, streaming, and front-panel microphone jack remapping High-quality stereo playback output with a 120 dB SNR and recording input with a 110 dB SNR Supports playback up to 32-bit/384 kHz on the front panel Audio Features SupremeFX Shielding Technology Savitech SV3H712 Amplifier Gold-plated audio jacks Rear optical S/PDIF output Premium audio capacitors Audio shield *A chassis with an HD audio module on the front panel is required for 7.1 Surround Sound audio output.**The rear-panel LINE OUT port does not support surround sound. If you want to enjoy surround sound, connect your audio output device to the audio jack on the front panel of the case or use a USB audio device.
Network interfaceBluetooth
Network interfaceWi-Fi 802.11a/b/g/n/ac/ax/be
Network interface1 x 10/100/1000/2500/5000 Mbit/s
Network interfaceEthernet 1 x Realtek 5Gb Ethernet ASUS LANGuard Wireless and Bluetooth Wi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6 GHz frequency bands** Supports Wi-Fi 7 320 MHz band, up to 5.8 Gbps transfer speeds. Bluetooth v5.4*** *Wi-Fi features may vary by operating system.For Windows 11, Wi-Fi 7 will require version 24H2 or later for full functionality. Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.For Windows 10, only Wi-Fi 6 is supported.**The Wi-Fi 6 GHz frequency band and bandwidth regulations may vary by country.***Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB ports at back panel11
USB ports on motherboard10
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports9
FireWire (IEEE 1394)No
COM connector / portNo
LPT connector / portNo
External connectors2 x Thunderbolt 4
External connectors4 x USB 3.1
External connectors1 x USB 3.1 Type-C
External connectors1 x Line Out
External connectors1 x MIC
External connectors1 x RJ-45
External connectors1 x S/PDIF
External connectors4 x USB 3.0
External connectors1 x PS/2 Keyboard/MouseCombo
External connectors1 x Przycisk Clear CMOS
External connectors1 x USB BIOS Flashback button
External connectors1 x Wi-Fi Module
Onboard connectors1 x USB BIOS Flashback button
Onboard connectors1 x OC PCIe switch
Onboard connectors1 x Front panel audio header
Onboard connectors1 x Power button
Onboard connectors2 x USB C
Onboard connectors1 x Thunderbolt header
Onboard connectors2 x USB 2.0/1.1 header
Onboard connectors2 x USB 3.0 header
Onboard connectors4 x SATA III 6Gb/s
Onboard connectors1 x System panel header
Onboard connectors1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors1 x Reset button
Onboard connectors1 x 4pin wentylator OPT CPU
Onboard connectors2 x 4pin Chassis fan
Onboard connectors1 x 4-pin water-pump-fan
Onboard connectors1 x 8pin 12V power
Onboard connectors1 x 24pin ATX zasilanie
Onboard connectors4 x M.2
Onboard connectors1 x 4pin CPU fan
Onboard connectors1 x Thermal sensor connector
Onboard connectors1 x LN2 Mode jumper
Onboard connectors1 x ReTry button
Onboard connectors3 x Addressable LED
Onboard connectors1 x Flex Key pin
BIOS2 x 256 Mb Flash ROM, UEFI AMI BIOS
Form factorATX
Dimensions30.5 cm x 24.4 cm
Accessories includedROG DIMM.2 with Heatsink M.2 Spacer for ROG DIMM.2 2 x M.2 Screw Packs for ROG DIMM.2 Thermal Pad for M.2 22110 ROG Memory Fan Kit ASUS Q-Slide WiFi Antenna Q-Connector ROG VIP Card 3 x M.2 Q-Slide Packs 5 x M.2 Backplate Rubber Packs ROG Bottle Opener USB Drive with Tools and Drivers Quick Start Guide
Supported operating systemsWindows 11
DesignationCE+WEEE
