| SKU | MOTPLKAMP000047 | | Barcode | 8885020628180 | | Resolution | 4K Ultra HD (3840 x 2160) | | Frames per second | 25 | | Lens | Type: Fixed-Focal Lens Focal Length: 4 mm Aperture: F1.6 Lens Mount: M12*P 0.5 Field of View: Horizontal Field of View: 91.5° Vertical Field of View: 46.1° Diagonal Field of View: 109.6° DORI Detection Distance: 107 m Observation: 44 m Recognition: 21 m Identification: 11 m | | Viewing angle, vertical | 46 | | Viewing angle, horizontal | 91 | | Visual angle diagonal | 109 | | Microphone | Yes | | Speakers built-in | Yes | | Two-way transmission | Yes | | Night mode | Yes | | Motion detection | Yes | | Management, monitoring, configuration | Smart Event: Intrusion Detection Line Crossing Detection Area Entry Detection Area Exit Detection Object Abandonment Detection Object Removal Detection Inactivity Detection People Detection Vehicle Detection Abnormal Sound Detection Scene Change Detection Basic Event: Motion Detection (extended to include people and vehicle classification for more accurate alerts) Video Tampering Detection Exception (illegal login) Emergency Call: Video Recording to Memory Card Push Message Audible Warning Flashing White Light | | Network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP | | Standards | 802.3at | | Standards | 802.3af | | Audio compression | G.711 | | Video compression | H.264+ | | Video compression | H.265 | | Video compression | H.265+ | | Video compression | H.264 | | Memory card reader | Yes | | Memory standard | SDXC | | Connectors | microSD | | Connectors | RJ-45 | | Protection class | IP67 | | Power supply | 12V DC 5%, max 10.5W, 5.5mm coaxial power plug PoE: 802.3af/at, Class 0, max 11.5W | | Environment requirements | Operating Temperature -30-60°C Storage Temperature -40-60°C Operating Humidity 95% or less (non-condensing) Storage Humidity 95% or less (non-condensing) | | Accessories included | VIGI Network Camera Quick Start Guide Waterproof Cable Brackets Mounting Accessories | | Color | White | | Dimensions | 184 × 74 × 74 mm | | Weight | 0.525 | | Certificates | CE, NTRA, VCCI, KC, BSMI, FCC, IC | | Designation | CE+WEEE |
|
