Home Computers and equipment Computer components Motherboard Gigabyte Z790 D AX Motherboard - Supports Intel Core 14th Gen CPUs, 12+1+1 Phases Digital VRM, up to 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2
Gigabyte Z790 D AX Motherboard - Supports Intel Core 14th Gen CPUs, 12+1+1 Phases Digital VRM, up to 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2

GIGABYTE

Gigabyte Z790 D AX Motherboard - Supports Intel Core 14th Gen CPUs, 12+1+1 Phases Digital VRM, up to 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2

Delivery to the store takes 3 - 7 business days.
ID: 163107
Product Code: Z790 D AX
Barcode 4719331860592
169.34€
(Ex Tax: 136.57€)
Payment options

Delivery options

omniva  venipak



Description
Description
Warranty period3 year(s)
Maximum internal memory supported by processor192 GB
Processor socketLGA 1700
Processor manufacturerIntel
Compatible processor seriesIntel® Core™ i7
Maximum number of SMP processors1
Supported processor socketsLGA 1700
Maximum resolution4096 x 2304 pixels
Parallel processing technology supportNot supported
HDCPYes
DirectX version12.0
Windows operating systems supportedWindows 11 x64
Motherboard form factorATX
Power source typeATX
PC health monitoringTemperature
Motherboard chipset familyIntel
Audio chipRealtek ALC897
Motherboard chipsetIntel Z790 Express
Audio output channels7.1 channels
Product colourBronze
Memory slots typeDIMM
Memory channelsDual-channel
Supported memory typesDDR5-SDRAM
Number of memory slots4
Supported memory clock speed (max)7600 MHz
Supported memory module capacities32GB
Supported memory clock speeds7000
Maximum internal memory192 GB
Unbuffered memoryYes
ECC сompatibilityECC & Non-ECC
Height35 mm
Width305 mm
Depth244 mm
Bluetooth version5.3
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
Wi-FiYes
Wi-Fi standards802.11g
Top Wi-Fi standardWi-Fi 6E (802.11ax)
WLAN controller modelIntel Wi-Fi 6E AX211
BluetoothYes
LAN controllerRealtek RTL8125
Number of SATA III connectors4
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
EPS power connector (8-pin)Yes
Front panel audio connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
RGB LED pin headerYes
Total number of SATA connectors4
Front panel connectorYes
USB 2.0 connectors2
Number of EATX power connectors2
CPU fan connectorYes
TPM connectorYes
Thunderbolt headers2
ATX Power connector (24-pin)Yes
12V power connectorYes
Desktop Management Interface (DMI) version2.7
Clear CMOS buttonYes
BIOS typeUEFI AMI
Clear CMOS jumperYes
Package weight1.84 kg
Package depth270 mm
Package width335 mm
Package height80 mm
Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software
Cables includedSATA
Antenna includedYes
Batteries includedYes
RAID levels10
Number of storage drives supported7
RAID supportYes
Number of HDDs supported4
Supported storage drive interfacesM.2, SATA III
Supported storage drive typesHDD & SSD
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
Ethernet LAN (RJ-45) ports1
Headphone outputs1
HDMI ports quantity1
PS/2 ports quantity1
DisplayPort version1.2
DisplayPorts quantity1
USB connector typeUSB Type-C
USB 2.0 ports quantity2
Microphone inYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
WiFi-AP antenna jack2
HDMI version2.1
USB 3.2 Gen 2x2 Type-C ports quantity1
S/PDIF out portYes
PCI Express x16 (Gen 4.x) slots1
PCI Express x1 (Gen 3.x) slots2
Number of M.2 (M) slots3
PCI Express x16 (Gen 3.x) slots1
PCI Express x16 (Gen 5.x) slots1
Number of battery cells1
Battery typeCR2032
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Battery weight3 g
Lithium weight per battery0.07 g
Products per shipping (inner) case1 pc(s)
Country of originChina
