Home Computers and equipment Computer components Motherboard Asrock B860M-H2 motherboard
Asrock B860M-H2 motherboard

Asrock B860M-H2 motherboard

Delivery to the store takes 3 - 7 business days.
ID: 163133
Product Code: B860M-H2
Barcode 4711581490437
93.53€
(Ex Tax: 75.43€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor manufacturerIntel
Supported processor socketsLGA 1851
Processor socketLGA 1851 (Socket V1)
CertificationFCC, CE, ErP/EuP
Audio output channels7.1 channels
Motherboard chipsetIntel B860
Motherboard form factormicro ATX
Audio chipRealtek ALC897
Motherboard chipset familyIntel
Windows operating systems supportedWindows 11 x64
Unbuffered memoryYes
Maximum internal memory128 GB
Memory channelsDual-channel
Memory slots typeDIMM
ECC сompatibilityNon-ECC
Supported memory typesDDR5-SDRAM
Number of memory slots2
Depth211 mm
Width244 mm
BluetoothNo
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerRealtek 8111H
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiNo
Ethernet LANYes
ATX Power connector (24-pin)Yes
USB 2.0 connectors2
Number of SATA III connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of water pump connectors1
Number of CPU fan connectors1
Number of RGB LED pin headers1
Number of chassis fan connectors2
TPM connectorYes
Number of USB 3.2 Gen 2 Type-C ports1
CPU fan connectorYes
RGB LED pin headerYes
12V power connectorYes
BIOS typeUEFI AMI
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, PCI Express 4.0, SATA III
RAID supportYes
RAID levels10
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity2
USB connector typeUSB Type-C
HDMI version2.1
Flashback BIOS buttonYes
Antennas quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
HDMI ports quantity2
Number of M.2 (M) slots2
Number of SATA III connectors4
1st M.2 highest PCI Express generation4.0
1st M.2 largest key size2280
PCI Express x16 (Gen 4.x) slots1
WarningsWhen disposing of the product, follow local regulations for the recycling of electronics.
