Asus ROG STRIX B860-F GAMING WIFI Intel B860 LGA 1851 (Socket V1) ATX

Asus ROG STRIX B860-F GAMING WIFI Intel B860 LGA 1851 (Socket V1) ATX

Delivery to the store takes 3 - 7 business days.
ID: 163148
Product Code: 90MB1JG0-M0EAY0
Barcode 4711387806951
302.03€
(Ex Tax: 243.57€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor manufacturerIntel
Compatible processor seriesIntel Core Ultra (Series 2)
Processor socketLGA 1851 (Socket V1)
Parallel processing technology supportNot supported
Audio output channels7.1 channels
Motherboard form factorATX
Windows operating systems supportedWindows 11
Motherboard chipsetIntel B860
Audio chipRealtek ALC4080
Product colourMulticolour
Motherboard chipset familyIntel
Number of memory slots4
Memory slots typeDIMM
Supported memory typesDDR5-SDRAM
Memory channelsDual-channel
Unbuffered memoryYes
Maximum internal memory256 GB
Supported memory clock speed (max)9066 MHz
ECC сompatibilityNon-ECC
Depth244 mm
Width305 mm
Height50 mm
Ethernet LANYes
Wi-FiYes
Bluetooth version5.4
Ethernet interface type2.5 Gigabit Ethernet
BluetoothYes
Top Wi-Fi standardWi-Fi 7 (802.11be)
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
12V power connectorYes
Number of SATA III connectors4
ATX Power connector (24-pin)Yes
EPS power connector (8-pin)Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Thunderbolt headers1
Front panel audio connectorYes
Chassis intrusion connectorYes
CPU fan connectorYes
Number of chassis fan connectors4
USB 2.0 connectors2
Number of CPU fan connectors1
BIOS typeUEFI AMI
Clear CMOS buttonYes
Package width350 mm
Package weight2.29 kg
Package depth265 mm
Package height71 mm
Number of HDDs supported4
Number of storage drives supported8
RAID supportYes
Supported storage drive interfacesM.2, SATA III
Supported storage drive typesHDD & SSD
Thunderbolt ports quantity1
Microphone inYes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
Ethernet LAN (RJ-45) ports1
DisplayPorts quantity1
HDMI ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
S/PDIF out portYes
USB 3.2 Gen 2x2 Type-C ports quantity1
PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots4
Weight1.51 kg
WarningsDo not open or modify the motherboard to prevent damage.
