Home Computers and equipment Computer components Motherboard Gigabyte X870E AORUS ELITE WIFI7 Motherboard - Supports AMD Ryzen 9000 CPUs, 16+2+2 Phases Digital VRM, up to 8000Hz DDR5 (OC), 3xPCIe 5.0 + 1xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, USB 4
Gigabyte X870E AORUS ELITE WIFI7 Motherboard - Supports AMD Ryzen 9000 CPUs, 16+2+2 Phases Digital VRM, up to 8000Hz DDR5 (OC), 3xPCIe 5.0 + 1xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, USB 4

GIGABYTE

Gigabyte X870E AORUS ELITE WIFI7 Motherboard - Supports AMD Ryzen 9000 CPUs, 16+2+2 Phases Digital VRM, up to 8000Hz DDR5 (OC), 3xPCIe 5.0 + 1xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, USB 4

Delivery to the store takes 3 - 7 business days.
ID: 163211
Product Code: X870E AORUS ELITE WIFI7
Barcode 4719331864613
290.04€
(Ex Tax: 233.91€)
Payment options

Delivery options

omniva  venipak



Description
Description
Warranty period3 year(s)
Compatible processor seriesAMD Ryzen 7000 Series
Processor manufacturerAMD
Processor socketSocket AM5
Maximum internal memory supported by processor256 GB
Supported processor socketsSocket AM5
On-board graphics cardNo
Parallel processing technology supportNot supported
DirectX version12.0
PC health monitoringFan
Windows operating systems supportedWindows 11 x64
Audio output channels7.1 channels
Motherboard form factorATX
Audio chipRealtek ALC1220
Motherboard chipset familyAMD
Product colourBlack
Motherboard chipsetAMD X870E
Memory slots typeDIMM
Supported memory typesDDR5-SDRAM
Supported memory clock speed (max)8200 MHz
Memory channelsDual-channel
Number of memory slots4
ECC сompatibilityNon-ECC
Maximum internal memory per slot64 GB
Supported memory module capacities2GB
Supported memory clock speeds6000
Unbuffered memoryYes
Maximum internal memory256 GB
Depth244 mm
Width305 mm
Height35 mm
WLAN controller modelMediaTek MT7925
Bluetooth version5.4
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiYes
Ethernet LANYes
Wi-Fi standardsWi-Fi 7 (802.11be)
Top Wi-Fi standardWi-Fi 7 (802.11be)
LAN controllerRealtek RTL8125
BluetoothYes
ATX Power connector (24-pin)Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
EPS power connector (8-pin)Yes
Front panel audio connectorYes
USB 2.0 connectors2
Number of SATA III connectors4
CPU fan connectorYes
TPM connectorYes
RGB LED pin headerYes
Front panel connectorYes
Number of chassis fan connectors4
Number of CPU fan connectors2
Number of RGB LED pin headers4
Number of EPS power connectors (8-pin)2
USB 3.2 Gen 2x2 connectors1
Number of water pump connectors2
BIOS typeUEFI AMI
Clear CMOS buttonYes
Clear CMOS jumperYes
Desktop Management Interface (DMI) version2.7
Package weight2.74 kg
Package width345 mm
Package depth294 mm
Package height80 mm
Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software
Batteries includedYes
Antenna includedYes
Screws includedYes
Supported storage drive typesHDD & SSD
RAID levels10
Supported storage drive interfacesM.2, SATA III
RAID supportYes
Number of storage drives supported8
Number of HDDs supported4
USB 2.0 ports quantity4
Microphone inYes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Headphone outputs1
HDMI version2.1
WiFi-AP antenna jack2
S/PDIF out portYes
DisplayPort version1.4
USB4 Gen 2x2 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
PCI Express x16 (Gen 5.x) slots1
Number of M.2 (M) slots4
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 3.x) slots1
PCI Express x4 slots2
1st M.2 largest key size25110
3rd M.2 largest key size22110
2nd M.2 largest key size22110
1st M.2 highest PCI Express generation5.0
2nd M.2 highest PCI Express generation5.0
3rd M.2 highest PCI Express generation5.0
4th M.2 highest PCI Express generation4.0
4th M.2 largest key size22110
Number of battery cells1
Battery typeCR2032
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Battery weight3 g
Lithium weight per battery0.07 g
Weight2.4 kg
Products per shipping (inner) case1 pc(s)
Country of originChina
WarningsAvoid contact with liquids to prevent electronic damage.
