Home Computers and equipment Computer components Motherboard MSI Motherboard MAG B850M MORTAR WIFI AM5 4DDR5 mATX
MSI Motherboard MAG B850M MORTAR WIFI AM5 4DDR5 mATX

MSI

MSI Motherboard MAG B850M MORTAR WIFI AM5 4DDR5 mATX

Delivery to the store takes 3 - 7 business days.
ID: 165663
Product Code: MAG B850M MORTAR WIFI
Barcode 4711377321150
217.64€
(Ex Tax: 175.52€)
Payment options

Delivery options

omniva  venipak



Specification
Description
Specification
artikuls: KBMSIAA8B850U00
svītrkods: 4711377321150
Description
SKUKBMSIAA8B850U00
Barcode4711377321150
ModelMAG B850M MORTAR WIFI
CPU socketSocket AM5
Processor familyAMD Ryzen
Integrated CPUNo
Chipset manufacturerAMD
Chipset typeAMD B850
Memory typeDDR5
Number of DDR5 slots4
Memory bus frequency8200 MHz
Max memory size256
Expansion slots1 x PCIe 5.0 x 16
Expansion slots1 x PCIe 4.0 x 4
Max. number of SATA devices4
RAIDYes
Detailed data on disk/drive interfaces3 x M.2: M.2_1 Source (From CPU) supports up to PCIe 5.0 x4, supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 5.0 x4, supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2, supports 2280 devices 4 x SATA 6G
Graphics1 x HDMI - Support HDMI 2.1 FRL, maximum resolution of 8K 60Hz
Sound cardRealtek ALC4080 Codec 7.1-Channel USB High Performance Audio Supports up to 32-bit/384kHz playback on front panel Supports S/PDIF output
Network interface1 x 10/100/1000/2500/5000 Mbit/s
Network interfaceWi-Fi 802.11a/b/g/n/ac/ax/be
Network interfaceBluetooth
Network interfaceRealtek 8126-VB 5G LAN Wireless: Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM
USB ports at back panel9
USB ports on motherboard7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports5
FireWire (IEEE 1394)No
COM connector / portNo
LPT connector / portNo
External connectors2 x SMA
External connectors4 x USB 3.2 Gen 1 Type-A
External connectors3 x USB 3.2 Gen 2 Type-A
External connectors1 x USB 3.2 Gen 2 Type-C
External connectors1 x USB 3.2 Gen 2x2 Type-C
External connectors1 x HDMI
External connectors1 x Line Out
External connectors1 x MIC
External connectors1 x RJ-45
External connectors1 x Przycisk Clear CMOS
External connectors1 x Flash BIOS Button
External connectors1 x S/PDIF
Onboard connectors3 x Addressable LED
Onboard connectors4 x EZ Debug LED
Onboard connectors1 x TPM header
Onboard connectors2 x System panel header
Onboard connectors2 x 8pin 12V
Onboard connectors1 x 24pin ATX zasilanie
Onboard connectors3 x M.2
Onboard connectors4 x SATA III 6Gb/s
Onboard connectors4 x USB 2.0/1.1
Onboard connectors2 x USB 3.2 Gen 1 Type-A
Onboard connectors1 x Chassis intrusion header
Onboard connectors1 x EZ Conn-header
Onboard connectors1 x EZ Memory Detection LED
Onboard connectors1 x Tuning Controller connector
Onboard connectors1 x Front panel audio header
Onboard connectors1 x 4pin CPU fan
Onboard connectors1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors4 x 4pin Chassis fan
Onboard connectors1 x 8-pin PCIe
Onboard connectors1 x USB 3.2 Gen 2 Type-C
Onboard connectors1 x RGB LED strip header
Form factormicro ATX
Dimensions243.84 x 243.84 mm
Supported operating systemsWindows 11
DesignationCE+WEEE
