Asus Motherboard ROG STRIX Z890-E GAMING WIFI s1851 4DDR5 TB4 ATX/90MB1IM0-M0EAY0

Asus Motherboard ROG STRIX Z890-E GAMING WIFI s1851 4DDR5 TB4 ATX/90MB1IM0-M0EAY0

Delivery to the store takes 3 - 7 business days.
ID: 167281
Product Code: ROG STRIX Z890-E GAMING WIFI
Barcode 4711387756133
541.35€
(Ex Tax: 436.57€)
Payment options

Delivery options

omniva  venipak



Specification
Description
Specification
artikuls: KBASUIIFZ890A05
svītrkods: 4711387756133
Description
SKUKBASUIIFZ890A05
Barcode4711387756133
ModelROG STRIX Z890-E GAMING WIFI
CPU socketLGA1851
Processor familyIntel Core Ultra
Integrated CPUNo
Chipset manufacturerIntel
Chipset typeIntel Z890 Chipset
Memory typeDDR5
Number of DDR5 slots4
Memory bus frequency8800 MHz
Max memory size192
Expansion slots1 x PCIe 4.0 x 16
Expansion slots1 x PCIe 5.0 x 16
Expansion slots7 x M.2
Max. number of SATA devices4
RAIDYes
Detailed data on disk/drive interfacesIntel Core Ultra Processors(series 2)*M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**Intel Z890 ChipsetM.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)M.2_6 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)M.2_7 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)4 x SATA 6Gb/s ports* Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5.** M.2_2 & M.2_3 slots share bandwidth with PCIEX16(G5). When M.2_2 & M.2_3 are occupied with SSD devices, PCIEX16(G5) will run x8 only.
Graphics1 x DisplayPort* 1 x HDMI port** 2 x Intel Thunderbolt 4 ports support DisplayPort and Thunderbolt video output*** * Supports up to 8K@60Hz according to the DisplayPort 1.4 specification.** Supports up to 4K@60Hz according to the HDMI 2.1 specification.*** Supports up to 8K@60Hz x1 with DSC or 4K@60Hz x2, maximum total bandwidth up to 23.8 Gbps or 16 Gbps/16 Gbps. Refer to the DisplayPort 2.1 specification for supported resolutions.*** Graphics specifications may vary depending on processor type. Refer to AMD processor specifications.
Sound cardROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080* Impedance sensing for front and rear headphone outputs Supports: jack detection, streaming, and front-panel microphone jack remapping High-quality stereo playback output with a SNR of 120 dB and recording input with a SNR of 110 dB Supports playback up to 32-bit/384 kHz Audio Features Audio Shielding Savitech SV3H712 Amplifier Gold-Plated Audio Jacks Rear Optical S/PDIF Output Premium Audio Capacitors Audio Shield *The rear-panel LINE OUT port does not support surround sound. To enjoy surround sound, connect your audio output device to the front-panel audio jack or use a USB audio device.
Network interface1 x 10/100/1000/2500/5000 Mbit/s
Network interfaceBluetooth
Network interfaceWi-Fi 802.11a/b/g/n/ac/ax/be
Network interfaceEthernet 1 x Realtek 5Gb Ethernet ASUS LANGuard Wireless and Bluetooth Wi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6 GHz frequency bands** Supports Wi-Fi 7 320 MHz band, up to 5.8 Gbps transfer speeds. Bluetooth v5.4*** *Wi-Fi features may vary by operating system.For Windows 11, Wi-Fi 7 will require version 24H2 or later for full functionality. Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.For Windows 10, only Wi-Fi 6 is supported.**The Wi-Fi 6 GHz frequency band and bandwidth regulations may vary by country.***Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB ports at back panel14
USB ports on motherboard11
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports5
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports12
FireWire (IEEE 1394)No
COM connector / portNo
LPT connector / portNo
External connectors1 x S/PDIF
External connectors3 x USB 3.0
External connectors7 x USB 3.1
External connectors2 x USB 3.1 Type-C
External connectors1 x MIC
External connectors1 x RJ-45
External connectors1 x HDMI
External connectors1 x Line Out
External connectors1 x DisplayPort
External connectors2 x Thunderbolt 4
External connectors1 x Przycisk Clear CMOS
External connectors1 x USB BIOS Flashback button
External connectors1 x Wi-Fi Module
Onboard connectors1 x Power button
Onboard connectors1 x 4pin wentylator OPT CPU
Onboard connectors5 x 4pin Chassis fan
Onboard connectors1 x 4-pin water-pump-fan
Onboard connectors2 x 8pin 12V
Onboard connectors1 x 24pin ATX zasilanie
Onboard connectors7 x M.2
Onboard connectors4 x SATA III 6Gb/s
Onboard connectors3 x USB 2.0/1.1 header
Onboard connectors2 x USB 3.0 header
Onboard connectors1 x USB C
Onboard connectors1 x System panel header
Onboard connectors1 x Front panel audio header
Onboard connectors1 x Thermal sensor connector
Onboard connectors1 x 4pin CPU fan
Onboard connectors1x CPU/DRAM overvoltage jumper
Onboard connectors3 x Addressable LED
Onboard connectors1 x Flex Key pin
BIOS256 Mb  Flash ROM, UEFI AMI BIOS
Form factorATX
Accessories included2 x SATA 6Gb/s Cable Thermal Pad for M.2 22110 ASUS Wi-Fi Movable Antennas Cable Tie Set M.2 Q-Latch Pack 2 x M.2 Q-Slides ROG Keychain ROG Strix Stickers 7 x M.2 Rubber Bands Quick Start Guide
Supported operating systemsWindows 11
SoftwareROG Exclusive Software- ROG CPU-Z- Dolby AtmosASUS Exclusive SoftwareArmoury Crate- AIDA64 Extreme (60 days free trial) - Aura Creator- Aura Sync- Fan Xpert 4 (with AI Cooling II)- GameFirst- HWiNFO- Power SavingASUS Driver HubASUS GlideXTurboV Core USB Wattage WatcherAdobe Creative Cloud (Free Trial)Norton 360 for Gamers (60 Days Free Trial)WinRAR (40 Days Free Trial)UEFI BIOSAI Overclocking GuideASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode- ASUS MyHotkeyNPU BoostFlexKey
DesignationCE+WEEE
