Home Computers and equipment Computer components Motherboard Asrock B850 Steel Legend WiFi AMD B850 Socket AM5 ATX
Asrock B850 Steel Legend WiFi AMD B850 Socket AM5 ATX

Asrock B850 Steel Legend WiFi AMD B850 Socket AM5 ATX

Delivery to the store takes 3 - 7 business days.
ID: 167582
Product Code: B850 STEEL LEGEND WIFI
Barcode 4711581490062
187.51€
(Ex Tax: 151.22€)
Payment options

Delivery options

omniva  venipak



Description
Description
Compatible processor seriesAMD Ryzen 9000 Series
Processor manufacturerAMD
Supported processor socketsSocket AM5
Processor socketSocket AM5
HDCPYes
Parallel processing technology supportNot supported
Maximum resolution3840 x 2160 pixels
CertificationFCC, CE, ErP/EuP
Audio chipRealtek ALC4082
Product colourWhite
Motherboard chipsetAMD B850
Motherboard chipset familyAMD
Motherboard form factorATX
Audio output channels7.1 channels
Windows operating systems supportedWindows 11 x64
Supported memory typesDDR5-SDRAM
Number of memory slots4
Maximum internal memory256 GB
Unbuffered memoryYes
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilityECC & Non-ECC
Depth244 mm
Width305 mm
Wi-Fi standardsWi-Fi 4 (802.11n)
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Bluetooth version5.4
Wi-FiYes
BluetoothYes
Top Wi-Fi standardWi-Fi 7 (802.11be)
LAN controllerDragon RTL8125BG
CPU fan connectorYes
Number of chassis fan connectors3
12V power connectorYes
TPM connectorYes
Number of SATA III connectors4
USB 2.0 connectors2
RGB LED pin headerYes
ATX Power connector (24-pin)Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
EPS power connector (8-pin)Yes
Front panel audio connectorYes
USB 3.2 Gen 2x2 connectors1
Number of EPS power connectors (8-pin)2
Number of CPU fan connectors2
Number of RGB LED pin headers1
BIOS typeUEFI AMI
Antenna includedYes
Cables includedSATA
RAID levels1
Number of storage drives supported8
Supported storage drive interfacesPCI Express 4.0, PCI Express 5.0, SATA III
RAID supportYes
Supported storage drive typesHDD & SSD
USB connector typeUSB Type-C
HDMI version2.1
WiFi-AP antenna jack2
S/PDIF out portYes
Headphone outputs2
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Microphone inYes
Line-inYes
HDMI ports quantity1
USB 2.0 ports quantity4
1st M.2 largest key size2280
2nd M.2 highest PCI Express generation4.0
3rd M.2 largest key size2280
4th M.2 highest PCI Express generation4.0
3rd M.2 highest PCI Express generation4.0
1st M.2 highest PCI Express generation5.0
4th M.2 largest key size2280
2nd M.2 largest key size2280
PCI Express x16 (Gen 5.x) slots1
PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots4
WarningsDo not disassemble to avoid damage to internal components and loss of warranty.
