Asrock B860M-X Intel B860 LGA 1851 (Socket V1) micro ATX

Asrock B860M-X Intel B860 LGA 1851 (Socket V1) micro ATX

Delivery to the store takes 3 - 7 business days.
ID: 168426
Product Code: B860M-X
Barcode 4711581490406
106.37€
(Ex Tax: 85.78€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor manufacturerIntel
Compatible processor seriesIntel Core Ultra (Series 2)
Processor socketLGA 1851 (Socket V1)
On-board graphics cardYes
Motherboard chipsetIntel B860
Product colourBlack
Audio chipRealtek ALC897
Motherboard form factormicro ATX
Motherboard chipset familyIntel
Windows operating systems supportedWindows 11 x64
Audio output channels7.1 channels
Supported memory clock speed (max)9066 MHz
ECC сompatibilityNon-ECC
Maximum internal memory128 GB
Unbuffered memoryYes
Supported memory typesDDR5-SDRAM
Memory slots typeDIMM
Number of memory slots2
Memory channelsDual-channel
Depth218 mm
Width244 mm
LAN controllerDragon RTL8125BG
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiNo
Number of EPS power connectors (8-pin)1
Number of CPU fan connectors2
RGB LED pin headerYes
Peripheral (Molex) power connectors (4-pin)1
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
CPU fan connectorYes
Front panel audio connectorYes
TPM connectorYes
Number of SATA III connectors4
ATX Power connector (24-pin)Yes
Number of chassis fan connectors2
EPS power connector (8-pin)Yes
BIOS typeUEFI AMI
Cables includedSATA
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
RAID levels1
RAID supportYes
USB 3.2 Gen 2x2 Type-C ports quantity1
Line-inYes
Microphone inYes
USB 2.0 ports quantity2
DisplayPorts quantity1
HDMI ports quantity1
Ethernet LAN (RJ-45) ports1
DisplayPort version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
PCI Express x4 (Gen 4.x) slots1
PCI Express x1 (Gen 4.x) slots1
PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots1
