Gigabyte Motherboard X870 A ELITE WF7 ICE AM 5 4DDR5 HDMI/USB-C ATX

GIGABYTE

Gigabyte Motherboard X870 A ELITE WF7 ICE AM 5 4DDR5 HDMI/USB-C ATX

Delivery to the store takes 3 - 7 business days.
ID: 170524
Product Code: X870 A ELITE WF7 ICE
Barcode 4719331864682
258.45€
(Ex Tax: 208.43€)
Payment options

Delivery options

omniva  venipak



Specification
Description
Specification
artikuls: KBGBAAA8X870A01
svītrkods: 4719331864682
Description
SKUKBGBAAA8X870A01
Barcode4719331864682
ModelX870 A ELITE WF7 ICE
CPU socketSocket AM5
Processor familyAMD Ryzen 7
Processor familyAMD Ryzen 5
Processor familyAMD Ryzen 9
Processor familyAMD Ryzen 3
Integrated CPUYes
Chipset manufacturerAMD
Chipset typeAMD X870
Memory typeDDR5
Number of DDR5 slots4
Memory bus frequency6200 MHz
Memory bus frequency7200 MHz
Memory bus frequency7600 MHz
Memory bus frequency6400 MHz
Memory bus frequency6600 MHz
Memory bus frequency6666 MHz
Memory bus frequency6800 MHz
Memory bus frequency4400 MHz
Memory bus frequency4800 MHz
Memory bus frequency5200 MHz
Memory bus frequency5600 MHz
Memory bus frequency6000 MHz
Memory bus frequency7000 MHz
Memory bus frequency7800 MHz
Memory bus frequency8000 MHz
Max memory size256
Expansion slots1 x PCIe 4.0 x 16
Expansion slots1 x PCIe x 16
Expansion slots1 x PCIe 3.0 x 16
Expansion slots1 x M.2
Max. number of SATA devices4
RAIDYes
Detailed data on disk/drive interfacesExpansion Slots1 PCI Express x16 (PCIEX16) slot, integrated with the processor:AMD Ryzen 9000/7000 series processors support PCIe 5.0 x16 mode* M2B_CPU and M2C_CPU slots share bandwidth with PCIEX16 slot.When M2B_CPU or M2C_CPU slot is occupied, PCIEX16 slot operates at up to x8 mode.AMD Ryzen 8000 Series-Phoenix 1 processors support PCIe 4.0 x8 modeAMD Ryzen 8000 Series-Phoenix 2 processors support PCIe 4.0 x4 mode(The PCIEX16 slot only supports a graphics card or NVMe SSD. If you only want to install one graphics card, you must install it in the PCIEX16 slot.)Chipset:- 1 PCI Express x16 slot, supporting PCIe 4.0 and operating at x4 mode (PCIEX4)* The PCIEX4 slot shares bandwidth with the M2D_SB connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2D_SB connector.- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 speed (PCIEX2)Storage Interface1 x M.2 connector (M2A_CPU), integrated with the processor, supporting socket 3, M key, type 25110/22110/2580/2280 SSD:AMD Ryzen 9000/7000 series processors support PCIe 5.0 x4/x2 SSDsAMD Ryzen 8000-Phoenix 1 series processors support PCIe 4.0 x4/x2 SSDsAMD Ryzen 8000-Phoenix 2 series processors support PCIe 4.0 x4/x2 SSDs2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated with the processor, supporting socket 3, M key, type 22110/2280 SSDs:AMD Ryzen 9000/7000 series processors support PCIe 5.0 x4/x2 SSDs* M2B_CPU and M2C_CPU connectors become unavailable when AMD Ryzen 8000-Phoenix 1/Phoenix 2 series processors are used.1 x M.2 connector (M2D_SB), integrated into the chipset, supporting Socket 3, M-Key, Type 22110/2280 PCIe 4.0 x4/x2 SSD4 x SATA 6Gb/s connectors Supports RAID 0, RAID 1, RAID 5, and RAID 10 for NVMe SSD storage devices* RAID 5 is only available on AMD Ryzen 9000 series processors.Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
GraphicsIntegrated graphics processor with AMD Radeon Graphics support + ASMedia USB4 controller:- 2 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz* Support DisplayPort version 1.4 and HDR.Integrated graphics processor with AMD Radeon Graphics support:- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz* Support HDMI version 2.1, HDCP 2.3 and HDR.** Support native HDMI 2.1 TMDS compliant ports.- 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz* Support HDMI version 1.4(Graphics specifications may vary depending on processor support.) Support for up to four displays simultaneously.
Sound cardCODE Realtek ALC1220* The line-out jack on the rear panel supports DSD audio.High-resolution audio2/4/5.1/7.1-channel* The audio jack functionality can be changed via audio software. To configure 7.1-channel audio, you must access the audio software for audio settings.S/PDIF output support
Network interface1 x 10/100/1000/2500 Mbit/s
Network interfaceWi-Fi 802.11a/b/g/n/ac/ax
Network interfaceBluetooth
Network interfaceLANRealtek 2.5GbE LAN chip (2.5Gbps/1Gbps/100Mbps)Wireless Communication moduleMediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.4 Support for 11be 160MHz wireless standard Realtek Wi-Fi 7 RTL8922AE (PCB rev. 1.1) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.4 Support for 11be 160MHz wireless standard
USB ports at back panel12
USB ports on motherboard7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports3
FireWire (IEEE 1394)No
COM connector / portNo
LPT connector / portNo
External connectors1 x RJ-45
External connectors4 x USB 2.0
External connectors4 x USB 3.0
External connectors2 x SMA
External connectors2 x USB4 Type-C
External connectors2 x USB 3.1
External connectors1 x S/PDIF
External connectors1 x HDMI
External connectors1 x Q-Flash Plus button
Onboard connectors1 x Front panel audio header
Onboard connectors1 x Clear CMOS jumper
Onboard connectors1 x Power button
Onboard connectors1 x TPM header
Onboard connectors1 x System panel header
Onboard connectors1 x Reset button
Onboard connectors1 x USB C
Onboard connectors1 x HDMI
Onboard connectors4 x 4pin Chassis fan
Onboard connectors2 x 4pin case fan liquid cooling
Onboard connectors2 x 8pin 12V
Onboard connectors1 x 24pin ATX zasilanie
Onboard connectors4 x M.2
Onboard connectors4 x SATA III 6Gb/s
Onboard connectors2 x USB 2.0/1.1 header
Onboard connectors1 x USB 3.0 header
Onboard connectors1 x 4pin CPU fan
Onboard connectors1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors1 x Reset jumper
Onboard connectors2 x temperature sensor
Onboard connectors1 x Noise detection header
Onboard connectors1 x RGB LED strip header
Onboard connectors3 x Addressable LED
BIOS1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form factorATX
Dimensions30.5 cm x 24.4 cm
Supported operating systemsWindows 11
SoftwareNorton Internet Security (OEM version) LAN bandwidth management software
DesignationCE+WEEE
