Asus PRIME H810M-A-CSM Intel H810 LGA 1851 (Socket V1) micro ATX motherboard

Asus PRIME H810M-A-CSM Intel H810 LGA 1851 (Socket V1) micro ATX motherboard

Availability: Delivery to the store takes 3 - 7 business days.
ID: 23141
Product Code: 90MB1KK0-M0EAYC
Barcode 4711387844625
134.25€
(Ex Tax: 108.26€)
Payment options

Delivery options



Description
Description
Supported processor socketsLGA 1851
Processor manufacturerIntel
Compatible processor seriesIntel Core Ultra (Series 2)
Processor socketLGA 1851 (Socket V1)
Parallel processing technology supportNot supported
On-board graphics cardNo
Windows operating systems supportedWindows 11
Motherboard form factormicro ATX
Audio output channels7.1 channels
Motherboard chipset familyIntel
Product colourBlack
Motherboard chipsetIntel H810
Power source typeATX
Unbuffered memoryYes
Maximum internal memory128 GB
Memory slots typeDIMM
Memory channelsDual-channel
Number of memory slots2
Supported memory clock speed (max)6400 MHz
Supported memory typesDDR5-SDRAM
ECC сompatibilityNon-ECC
Height37 mm
Depth222 mm
Width244 mm
LAN controllerIntel I219V
Wake-on-LAN readyYes
Ethernet interface typeGigabit Ethernet
Ethernet LANYes
Wi-FiNo
Front panel connectorYes
ATX Power connector (24-pin)Yes
USB 2.0 connectors1
Front panel audio connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
EPS power connector (8-pin)Yes
Number of SATA III connectors4
S/PDIF out connectorYes
CPU fan connectorYes
Number of chassis fan connectors2
Number of COM connectors1
TPM connectorYes
RGB LED pin headerYes
Number of EPS power connectors (8-pin)1
Number of RGB LED pin headers3
Number of CPU fan connectors1
BIOS typeUEFI AMI
Package weight782 g
Package width270 mm
Package depth263 mm
Package height51.5 mm
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, PCI Express 4.0, SATA III
Number of storage drives supported6
Number of HDDs supported4
DisplayPort version1.4
USB 2.0 ports quantity4
Ethernet LAN (RJ-45) ports1
DisplayPorts quantity1
HDMI ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Line-inYes
HDMI version2.1
Microphone inYes
PS/2 ports quantity1
Number of M.2 (M) slots2
PCI Express x16 (Gen 4.x) slots1
PCI Express x1 (Gen 4.x) slots1
2nd M.2 largest key size2280
1st M.2 highest PCI Express generation4.0
2nd M.2 highest PCI Express generation4.0
1st M.2 largest key size2280
Weight534 g
Number of M.2 (E) slots1
WarningsIn case of installation problems, contact a qualified service technician.
