Asrock B860M Pro RS Intel B860 LGA 1851 (Socket V1) micro ATX

Asrock B860M Pro RS Intel B860 LGA 1851 (Socket V1) micro ATX

Availability: Delivery to the store takes 3 - 7 business days.
ID: 23163
Product Code: B860M PRO RS
Barcode 4711581490277
151.86€
(Ex Tax: 122.47€)
Payment options

Delivery options



Description
Description
Processor socketLGA 1851 (Socket V1)
Processor manufacturerIntel
Audio output channels7.1 channels
Motherboard chipsetIntel B860
Audio chipRealtek ALC897
Windows operating systems supportedWindows 11 x64
Motherboard form factormicro ATX
Motherboard chipset familyIntel
Supported memory typesDDR5-SDRAM
Memory slots typeDIMM
Number of memory slots4
Memory channelsDual-channel
Unbuffered memoryYes
Maximum internal memory256 GB
Width244 mm
Depth244 mm
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiNo
LAN controllerDragon RTL8125BG
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
RGB LED pin headerYes
USB 2.0 connectors2
EPS power connector (8-pin)Yes
Number of SATA III connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Number of EPS power connectors (8-pin)1
TPM connectorYes
ATX Power connector (24-pin)Yes
Number of CPU fan connectors2
Number of chassis fan connectors3
Front panel audio connectorYes
Number of RGB LED pin headers4
CPU fan connectorYes
BIOS typeEFI AMI
Cables includedSATA
Supported storage drive interfacesM.2, SATA III
RAID levels10
Number of storage drives supported7
RAID supportYes
USB 3.2 Gen 2x2 Type-C ports quantity1
Line-inYes
Microphone inYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
DisplayPorts quantity1
DisplayPort version1.4
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity2
HDMI ports quantity2
PCI Express x4 (Gen 4.x) slots1
Number of M.2 (M) slots1
PCI Express x16 (Gen 5.x) slots1
WarningsDo not open or modify the motherboard to prevent damage.
