Home Computers and equipment Computer components Motherboard Gigabyte A620M DS3H Motherboard - Supports AMD Ryzen 8000 CPUs, 5+2+2 Phases Digital VRM, up to 7600MHz DDR5 (OC), 1xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 1
Gigabyte A620M DS3H Motherboard - Supports AMD Ryzen 8000 CPUs, 5+2+2 Phases Digital VRM, up to 7600MHz DDR5 (OC), 1xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 1

Gigabyte A620M DS3H Motherboard - Supports AMD Ryzen 8000 CPUs, 5+2+2 Phases Digital VRM, up to 7600MHz DDR5 (OC), 1xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 1

Availability: Delivery to the store takes 3 - 7 business days.
ID: 23266
Product Code: A620M DS3H
Barcode 4719331855567
94.51€
(Ex Tax: 76.21€)
Payment options

Delivery options



Description
Description
Warranty period3 year(s)
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 7000 Series
Maximum internal memory supported by processor256 GB
Processor socketSocket AM5
Supported processor socketsSocket AM5
HDCP version2.3
HDCPYes
PC health monitoringVoltage
Motherboard chipsetAMD A620
Windows operating systems supportedWindows 10 x64
Audio output channels7.1 channels
Motherboard form factormicro ATX
Motherboard chipset familyAMD
Memory channelsDual-channel
Memory slots typeDIMM
Unbuffered memoryYes
Supported memory typesDDR5-SDRAM
Supported memory clock speed (max)7600 MHz
Supported memory clock speeds6400
Number of memory slots4
Maximum internal memory256 GB
ECC сompatibilityNon-ECC
Depth174 mm
Width244 mm
Ethernet LAN data rates1000 Mbit/s
Ethernet LANYes
Ethernet interface typeGigabit Ethernet
ATX Power connector (24-pin)Yes
USB 2.0 connectors1
EPS power connector (8-pin)Yes
Total number of SATA connectors4
TPM connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
CPU fan connectorYes
RGB LED pin headerYes
Front panel connectorYes
Number of SATA III connectors4
Front panel audio connectorYes
12V power connectorYes
BIOS typeUEFI AMI
Desktop Management Interface (DMI) version2.7
Clear CMOS jumperYes
Supported storage drive interfacesM.2, SATA III
RAID supportYes
Supported storage drive typesHDD & SSD
RAID levels10
Number of storage drives supported4
HDMI version2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB connector typeUSB Type-C
Headphone outputs3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
DisplayPort version1.4
DisplayPorts quantity1
USB 2.0 ports quantity4
PS/2 ports quantity1
Number of audio jack connectors3
HDMI ports quantity1
Ethernet LAN (RJ-45) ports1
VGA (D-Sub) ports quantity1
PCI Express x16 slots1
PCI Express x1 slots1
Number of M.2 (M) slots1
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Number of battery cells1
Battery typeCR2032
Battery weight3 g
Lithium weight per battery0.07 g
