Home Computers and equipment Computer components Motherboard Gigabyte B760 GAMING X DDR4 1.0 motherboard
Gigabyte B760 GAMING X DDR4 1.0 motherboard

GIGABYTE

Gigabyte B760 GAMING X DDR4 1.0 motherboard

Delivery to the store takes 3 - 7 business days.
ID: 96832
Product Code: B760 GAMING X DDR4
Barcode 4719331850906
115.47€
(Ex Tax: 93.12€)
Payment options

Delivery options

omniva  venipak



Description
Description
Supported processor socketsLGA 1700
Processor socketLGA 1700
Compatible processor seriesIntel® Core™ i5
Processor manufacturerIntel
HDCPYes
Parallel processing technology supportNot supported
Maximum resolution4096 x 2304 pixels
HDCP version2.3
Windows operating systems supportedWindows 11
PC health monitoringFan
Audio output channels7.1 channels
Motherboard form factorATX
Motherboard chipset familyIntel
Power source typeATX
Supported memory typesDDR4-SDRAM
Supported memory clock speeds3466
Memory channelsDual-channel
Memory slots typeDIMM
Maximum internal memory128 GB
Number of memory slots4
Supported memory clock speed (max)5333 MHz
Unbuffered memoryYes
Width305 mm
Depth244 mm
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Serial port headers1
EPS power connector (8-pin)Yes
Number of SATA III connectors4
ATX Power connector (24-pin)Yes
Front panel audio connectorYes
CPU fan connectorYes
Front panel connectorYes
RGB LED pin headerYes
TPM connectorYes
Number of chassis fan connectors3
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
S/PDIF out connectorYes
Desktop Management Interface (DMI) version2.7
Clear CMOS jumperYes
BIOS typeUEFI AMI
RAID levels5
Number of storage drives supported6
RAID supportYes
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
HDMI ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
DisplayPorts quantity1
Number of USB 3.2 Gen 2 Type-A ports1
Headphone outputs1
Ethernet LAN (RJ-45) ports1
Line-inYes
Microphone inYes
USB 2.0 ports quantity5
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 3.x) slots2
Number of M.2 (M) slots3
