Asus PRIME H810M-A-CSM Intel H810 LGA 1851 (Socket V1) micro ATX motherboard

Asus PRIME H810M-A-CSM Intel H810 LGA 1851 (Socket V1) micro ATX motherboard

Delivery to the store takes 3 - 7 business days.
ID: 96838
Product Code: 90MB1KK0-M0EAYC
Barcode 4711387844625
123.60€
(Ex Tax: 99.68€)
Payment options

Delivery options

omniva  venipak



Description
Description
Supported processor socketsLGA 1851
Processor socketLGA 1851 (Socket V1)
Compatible processor seriesIntel Core Ultra (Series 2)
Processor manufacturerIntel
Parallel processing technology supportNot supported
On-board graphics cardNo
Power source typeATX
Windows operating systems supportedWindows 10 x64
Audio output channels7.1 channels
Motherboard form factormicro ATX
Motherboard chipsetIntel H810
Motherboard chipset familyIntel
Product colourBlack
Maximum internal memory128 GB
Unbuffered memoryYes
Supported memory clock speed (max)6400 MHz
Number of memory slots2
Supported memory typesDDR5-SDRAM
Memory channelsDual-channel
Memory slots typeDIMM
ECC сompatibilityNon-ECC
Width244 mm
Depth222 mm
Height37 mm
Wake-on-LAN readyYes
LAN controllerIntel I219V
Wi-FiNo
Ethernet interface typeGigabit Ethernet
Ethernet LANYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
Number of SATA III connectors4
USB 2.0 connectors1
Number of COM connectors1
Front panel audio connectorYes
EPS power connector (8-pin)Yes
Number of chassis fan connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
S/PDIF out connectorYes
Front panel connectorYes
TPM connectorYes
RGB LED pin headerYes
Number of EPS power connectors (8-pin)1
Number of CPU fan connectors1
Number of RGB LED pin headers3
BIOS typeUEFI AMI
Package weight782 g
Package width270 mm
Package height51.5 mm
Package depth263 mm
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, PCI Express 4.0, SATA III
Number of HDDs supported4
Number of storage drives supported6
DisplayPorts quantity1
DisplayPort version1.4
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity4
PS/2 ports quantity1
HDMI version2.1
Microphone inYes
Line-inYes
HDMI ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Number of M.2 (M) slots2
PCI Express x16 (Gen 4.x) slots1
PCI Express x1 (Gen 4.x) slots1
2nd M.2 largest key size2280
1st M.2 largest key size2280
1st M.2 highest PCI Express generation4.0
2nd M.2 highest PCI Express generation4.0
Weight534 g
Number of M.2 (E) slots1
WarningsIn case of installation problems, contact a qualified service technician.
