Asrock B860I Lightning WiFi Motherboard

Asrock B860I Lightning WiFi Motherboard

Delivery to the store takes 3 - 7 business days.
ID: 96865
Product Code: B860I LIGHTNING WIFI
Barcode 4711581490420
213.04€
(Ex Tax: 171.80€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor socketLGA 1851 (Socket V1)
Supported processor socketsLGA 1851
Compatible processor seriesIntel Core Ultra (Series 2)
Processor manufacturerIntel
HDCPYes
On-board graphics card familyIntel Iris Xe Graphics
Maximum resolution7680 x 4320 pixels
CertificationFCC, CE, ErP/EuP
Product colourWhite
Windows operating systems supportedWindows 11 x64
Audio output channels7.1 channels
Motherboard form factorMini-ITX
Motherboard chipsetIntel B860
Audio chipRealtek ALC1220
Motherboard chipset familyIntel
Supported memory typesDDR5-SDRAM
Number of memory slots2
Unbuffered memoryYes
Maximum internal memory128 GB
Memory slots typeDIMM
ECC сompatibilityNon-ECC
Memory channelsDual-channel
Depth170 mm
Width170 mm
Wi-Fi standards802.11a
Bluetooth version5.3
MU-MIMOYes
Ethernet LAN data rates10,100,1000,2500 Mbit/s
Ethernet LANYes
Top Wi-Fi standardWi-Fi 6E (802.11axe)
BluetoothYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiYes
LAN controllerDragon RTL8125BG
Front panel audio connectorYes
12V power connectorYes
USB 2.0 connectors2
CPU fan connectorYes
Number of chassis fan connectors1
Number of CPU fan connectors1
Number of water pump connectors1
ATX Power connector (24-pin)Yes
Number of SATA III connectors3
Number of USB 3.2 Gen 2 Type-C ports1
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
BIOS typeUEFI AMI
RAID levels1
Number of storage drives supported5
Supported storage drive typesHDD & SSD
RAID supportYes
Supported storage drive interfacesPCI Express 4.0, PCI Express 5.0, SATA III
USB connector typeUSB Type-A
Ethernet LAN (RJ-45) ports1
S/PDIF out portYes
Thunderbolt ports quantity1
Number of USB 3.2 Gen 1 ports4
Flashback BIOS buttonYes
HDMI ports quantity1
Antennas quantity2
USB 2.0 ports quantity1
MIC input1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
2nd M.2 largest key size2280
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 5.x) slots1
1st M.2 largest key size2280
Number of M.2 (M) slots4
1st M.2 highest PCI Express generation5.0
Number of SATA III connectors3
2nd M.2 highest PCI Express generation4.0
WarningsDo not open or modify the motherboard to prevent damage.
