Asus PRIME B840M-A-CSM AMD B840 Socket AM5 micro ATX

Asus PRIME B840M-A-CSM AMD B840 Socket AM5 micro ATX

Availability: Delivery to the store takes 3 - 7 business days.
ID: 96982
Product Code: 90MB1J10-M0EAYC
Barcode 4711387797204
159.95€
(Ex Tax: 128.99€)
Payment options

Delivery options

omniva  venipak



Description
Description
Supported processor socketsSocket AM5
Processor socketSocket AM5
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 8000 Series
Maximum resolution7680 x 4320 pixels
Parallel processing technology supportNot supported
Windows operating systems supportedWindows 10 x64
Motherboard chipset familyAMD
Audio output channels7.1 channels
Power source typeATX
Motherboard chipsetAMD B840
Motherboard form factormicro ATX
Product colourGrey
ECC сompatibilityECC & Non-ECC
Supported memory clock speed (max)7600 MHz
Maximum internal memory192 GB
Supported memory typesDDR5-SDRAM
Memory channelsDual-channel
Unbuffered memoryYes
Memory slots typeDIMM
Number of memory slots4
Width244 mm
Depth244 mm
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiNo
Number of CPU fan connectors2
Number of RGB LED pin headers3
Number of EPS power connectors (8-pin)1
RGB LED pin headerYes
CPU fan connectorYes
Number of SATA III connectors4
Front panel audio connectorYes
EPS power connector (8-pin)Yes
Number of chassis fan connectors2
S/PDIF out connectorYes
ATX Power connector (24-pin)Yes
USB 2.0 connectors2
Number of COM connectors1
TPM connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Front panel connectorYes
BIOS typeUEFI AMI
Package height67.5 mm
Package weight1.45 kg
Package depth275 mm
Package width275 mm
Screws includedYes
Cables includedSATA
RAID levels10
Number of storage drives supported7
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
Number of HDDs supported4
RAID supportYes
HDMI version2.1
DisplayPorts quantity1
HDMI ports quantity1
Line-inYes
Ethernet LAN (RJ-45) ports1
DisplayPort version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
Headphone outputs1
USB 2.0 ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
2nd M.2 highest PCI Express generation4.0
1st M.2 largest key size2280
3rd M.2 largest key size2280
2nd M.2 largest key size2280
3rd M.2 highest PCI Express generation3.0
1st M.2 highest PCI Express generation4.0
PCI Express x16 (Gen 3.x) slots2
Number of M.2 (M) slots3
PCI Express x16 (Gen 4.x) slots1
Weight910 g
Quick installation guideYes
WarningsDo not disassemble to avoid damage to internal components and loss of warranty.
