Asus TUF GAMING B850-E WIFI AMD B850 Socket AM5 ATX

Asus TUF GAMING B850-E WIFI AMD B850 Socket AM5 ATX

Delivery to the store takes 3 - 7 business days.
ID: 97002
Product Code: 90MB1L20-M0EAY0
Barcode 4711387987544
252.06€
(Ex Tax: 203.27€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor socketSocket AM5
Compatible processor seriesAMD Ryzen 9000 Series
Processor manufacturerAMD
On-board graphics cardNo
Parallel processing technology supportNot supported
Windows operating systems supportedWindows 11
Cooling typePassive
Motherboard form factorATX
Product colourMulticolour
Audio output channels7.1 channels
Motherboard chipset familyAMD
Motherboard chipsetAMD B850
Memory slots typeDIMM
Supported memory typesDDR5-SDRAM
Number of memory slots4
Supported memory clock speed (max)8000 MHz
Memory channelsDual-channel
Unbuffered memoryYes
Maximum internal memory256 GB
ECC сompatibilityECC & Non-ECC
Height48 mm
Depth244 mm
Width305 mm
Bluetooth version5.3
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiYes
BluetoothYes
12V power connectorYes
RGB LED pin headerYes
EPS power connector (8-pin)Yes
Number of COM connectors1
Number of chassis fan connectors4
CPU fan connectorYes
Front panel connectorYes
Chassis intrusion connectorYes
Front panel audio connectorYes
Number of SATA III connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
ATX Power connector (24-pin)Yes
USB 2.0 connectors2
Number of CPU fan connectors1
USB 3.2 Gen 2x2 connectors1
Number of water pump connectors1
Number of RGB LED pin headers3
BIOS typeUEFI AMI
Package width353 mm
Package weight1.78 kg
Package depth273 mm
Package height68 mm
Antenna includedYes
RAID levels1
Number of HDDs supported4
Number of storage drives supported7
Supported storage drive interfacesM.2, SATA III
RAID supportYes
Supported storage drive typesHDD & SSD
USB 2.0 ports quantity3
USB connector typeUSB Type-A
Line-inYes
WiFi-AP antenna jack2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
Microphone inYes
HDMI ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
DisplayPorts quantity1
Number of M.2 (M) slots3
PCI Express x16 (Gen 4.x) slots1
PCI Express x1 (Gen 4.x) slots1
1st M.2 largest key size22110
1st M.2 highest PCI Express generation5.0
Weight1.21 kg
