Home Computers and equipment Computer components Motherboard Gigabyte B850M DS3H Motherboard - AMD Ryzen 9000 Series CPUs, 16+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 1xPCIe 4.0 M.2, 2.5 LAN, USB 3.2 Gen 2
Gigabyte B850M DS3H Motherboard - AMD Ryzen 9000 Series CPUs, 16+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 1xPCIe 4.0 M.2, 2.5 LAN, USB 3.2 Gen 2

Gigabyte B850M DS3H Motherboard - AMD Ryzen 9000 Series CPUs, 16+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 1xPCIe 4.0 M.2, 2.5 LAN, USB 3.2 Gen 2

Availability: Delivery to the store takes 3 - 7 business days.
ID: 97015
Product Code: B850M DS3H
Barcode 4719331866518
148.38€
(Ex Tax: 119.66€)
Payment options

Delivery options

omniva  venipak



Description
Description
Warranty period3 year(s)
Compatible processor seriesAMD Ryzen 9000 Series
Processor manufacturerAMD
Supported processor socketsSocket AM5
Processor socketSocket AM5
Parallel processing technology supportNot supported
HDCPYes
Maximum resolution4096 x 2160 pixels
DirectX version12.0
Windows operating systems supportedWindows 11 x64
Audio chipRealtek ALC897
Motherboard chipset familyAMD
PC health monitoringWater cooling
Power source typeATX
Audio output channels7.1 channels
Motherboard form factormicro ATX
Motherboard chipsetAMD B850
Product colourBronze
Memory slots typeDIMM
Memory channelsDual-channel
Supported memory typesDDR5-SDRAM
Number of memory slots4
Supported memory clock speeds4400 MHz
Maximum internal memory256 GB
Unbuffered memoryYes
Supported memory clock speed (max)8200 MHz
ECC сompatibilityNon-ECC
Maximum internal memory per slot64 GB
Height35 mm
Width244 mm
Depth244 mm
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
Wi-FiNo
CPU fan connectorYes
EPS power connector (8-pin)Yes
RGB LED pin headerYes
Peripheral (Molex) power connectors (4-pin)1
Total number of SATA connectors4
TPM connectorYes
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
Front panel connectorYes
12V power connectorYes
Front panel audio connectorYes
USB 2.0 connectors2
Number of SATA III connectors4
Serial port headers1
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
ATX Power connector (24-pin)Yes
Number of CPU fan connectors2
Number of RGB LED pin headers4
Number of EPS power connectors (8-pin)1
BIOS typeUEFI AMI
Clear CMOS jumperYes
Desktop Management Interface (DMI) version2.7
Clear CMOS buttonYes
Package depth268 mm
Package width270 mm
Package height68 mm
Package weight1.34 kg
Bundled softwareNorton Internet Security (OEM version) LAN bandwidth management software
Antenna includedYes
Batteries includedYes
Screws includedYes
RAID levels10
Number of HDDs supported4
Number of storage drives supported6
Supported storage drive typesHDD & SSD
RAID supportYes
Supported storage drive interfacesM.2, SATA III
HDMI version2.1
HDMI ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Headphone outputs1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
Microphone inYes
WiFi-AP antenna jack2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
DisplayPorts quantity2
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity4
DisplayPort version2.1
Number of M.2 (M) slots2
2nd M.2 largest key size25110
PCI Express x16 (Gen 3.x) slots1
2nd M.2 highest PCI Express generation4.0
1st M.2 largest key size25110
PCI Express x16 (Gen 5.x) slots1
1st M.2 highest PCI Express generation5.0
Battery typeCR2032
Battery weight3 g
Number of battery cells1
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery0.07 g
Weight1.14 kg
Products per shipping (inner) case1 pc(s)
Country of originChina
WarningsDispose of in accordance with local regulations for electronic waste.
