Gigabyte B650 GAMING X AX V2 Motherboard - AMD Ryzen 9000 Series CPUs, 8+2+2 Phases VRM, up to 8000MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, 2.5GbE LAN, WIFI 6E, USB 3.2 Gen 2

GIGABYTE

Gigabyte B650 GAMING X AX V2 Motherboard - AMD Ryzen 9000 Series CPUs, 8+2+2 Phases VRM, up to 8000MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, 2.5GbE LAN, WIFI 6E, USB 3.2 Gen 2

Delivery to the store takes 3 - 7 business days.
ID: 98462
Product Code: B650 GAMING X AX V2
Barcode 4719331860073
148.35€
(Ex Tax: 119.64€)
Payment options

Delivery options

omniva  venipak



Description
Description
Warranty period3 year(s)
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 9000 Series
Processor socketSocket AM5
Supported processor socketsSocket AM5
Maximum resolution4096 x 2160 pixels
Parallel processing technology supportNot supported
DirectX version12.0
HDCPYes
Windows operating systems supportedWindows 11 x64
Motherboard chipset familyAMD
Audio chipRealtek ALC897
PC health monitoringVoltage
Motherboard chipsetAMD B650
Power source typeATX
Audio output channels7.1 channels
Product colourBronze
Motherboard form factorATX
Memory channelsDual-channel
Supported memory clock speeds8000 MHz
Memory slots typeDIMM
Number of memory slots4
ECC сompatibilityNon-ECC
Supported memory clock speed (max)8000 MHz
Unbuffered memoryYes
Maximum internal memory per slot64 GB
Maximum internal memory256 GB
Supported memory typesDDR5-SDRAM
Height35 mm
Depth244 mm
Width305 mm
Wi-Fi standards802.11a
Top Wi-Fi standardWi-Fi 6E (802.11ax)
WLAN controller modelRealtek RTL8852CE
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiYes
Bluetooth version5.3
LAN controllerRealtek RTL8125
BluetoothYes
EPS power connector (8-pin)Yes
Number of RGB LED pin headers5
TPM connectorYes
RGB LED pin headerYes
Number of SATA III connectors4
Number of chassis fan connectors3
CPU fan connectorYes
USB 2.0 connectors2
Number of CPU fan connectors2
USB 3.2 Gen 2x2 connectors1
Serial port headers1
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Front panel connectorYes
ATX Power connector (24-pin)Yes
Number of EPS power connectors (8-pin)1
Number of water pump connectors2
Front panel audio connectorYes
12V power connectorYes
BIOS typeUEFI AMI
Clear CMOS jumperYes
Desktop Management Interface (DMI) version2.7
Package width335 mm
Package height80 mm
Package weight2.16 kg
Package depth270 mm
Bundled softwareNorton Internet Security (OEM version) LAN bandwidth management software
Batteries includedYes
Screws includedYes
Antenna includedYes
Supported storage drive typesHDD & SSD
Number of HDDs supported4
RAID supportYes
Number of storage drives supported7
Supported storage drive interfacesM.2, SATA III
HDMI version2.1
USB 2.0 ports quantity3
DisplayPorts quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Headphone outputs1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
Microphone inYes
HDMI ports quantity1
WiFi-AP antenna jack2
DisplayPort version1.4
Line-inYes
Ethernet LAN (RJ-45) ports1
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 3.x) slots2
Number of M.2 (M) slots3
1st M.2 highest PCI Express generation5.0
1st M.2 largest key size25110
2nd M.2 highest PCI Express generation4.0
2nd M.2 largest key size25110
3rd M.2 largest key size25110
3rd M.2 highest PCI Express generation4.0
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery0.07 g
Battery typeCR2032
Battery weight3 g
Number of battery cells1
Country of originChina
Products per shipping (inner) case1 pc(s)
WarningsDo not disassemble to avoid damage to internal components and loss of warranty.
