Home Computers and equipment Computer components Motherboard Asrock B760M-HDV/M.2 D4 Intel B760 LGA 1700 micro ATX
Asrock B760M-HDV/M.2 D4 Intel B760 LGA 1700 micro ATX

Asrock B760M-HDV/M.2 D4 Intel B760 LGA 1700 micro ATX

Delivery to the store in 5 to 7 business days.
ID: 167552
Model B760M-HDV/M.2 D4
Barcode 4710483942020
Brand: ASROCK
78.05€
(Ex Tax: 62.94€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor socketLGA 1700
Compatible processor seriesIntel® Core™ i5
Processor manufacturerIntel
Maximum number of SMP processors1
Parallel processing technology supportNot supported
HDCPYes
Certification- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)
Motherboard form factormicro ATX
Motherboard chipset familyIntel
Audio chipRealtek ALC897
Motherboard chipsetIntel B760
Audio output channels7.1 channels
Windows operating systems supportedWindows 10 Education x64
Supported memory typesDDR4-SDRAM
Unbuffered memoryYes
Supported memory clock speeds5333 MHz
Maximum internal memory64 GB
Number of memory slots2
Memory slots typeDIMM
ECC сompatibilityNon-ECC
Memory channelsDual-channel
Depth201 mm
Width244 mm
Ethernet LANYes
LAN controllerRealtek RTL8111H
Wi-FiNo
Ethernet interface typeGigabit Ethernet
USB 2.0 connectors3
CPU fan connectorYes
Chassis intrusion connectorYes
TPM connectorYes
Number of SATA III connectors4
ATX Power connector (24-pin)Yes
EPS power connector (8-pin)Yes
Front panel connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
BIOS typeUEFI AMI
Cables includedSATA
RAID levels10
RAID supportYes
Supported storage drive interfacesM.2, SATA III
DisplayPorts quantity1
VGA (D-Sub) ports quantity1
USB 2.0 ports quantity2
HDMI ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
DisplayPort version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Microphone inYes
PS/2 ports quantity1
Line-inYes
PCI Express x1 (Gen 3.x) slots2
PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots1
WarningsAvoid direct contact with electronics to prevent electrostatic damage.
