Asus P12R-I/ASMB10 Intel C252 LGA 1200 (Socket H5) ATX

Asus P12R-I/ASMB10 Intel C252 LGA 1200 (Socket H5) ATX

Delivery to the store in 5 to 7 business days.
ID: 171132
Model 90SB0A70-M0UAY0
Barcode 4711081507604
Brand: ASUS
325.77€
(Ex Tax: 262.72€)
Payment options

Delivery options

omniva  venipak



Description
Description
Processor socketLGA 1200 (Socket H5)
Compatible processor seriesIntel Xeon E
Processor manufacturerIntel
Graphics card familyASPEED
Graphics cardAST2600
On-board graphics card memory64 MB
Component forServer
Motherboard form factorATX
Motherboard chipsetIntel C252
Motherboard chipset familyIntel
Memory channelsDual-channel
Memory slots typeDIMM
Supported memory clock speeds2933
Maximum internal memory64 GB
Number of memory slots2
Supported memory module capacities32GB
Supported memory typesDDR4-SDRAM
Operating temperature (T-T)10 - 50 °C
Storage relative humidity (H-H)20 - 90%
Storage temperature (T-T)-40 - 70 °C
Depth170 mm
Width170 mm
Ethernet LANYes
Wi-FiNo
LAN controllerIntel® I210-AT
EPS power connector (8-pin)Yes
Serial port headers1
Number of SATA III connectors6
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of chassis fan connectors2
TPM connectorYes
ATX Power connector (24-pin)Yes
Chassis intrusion connectorYes
Package weight1.2 kg
Package width311 mm
Package height78 mm
Package depth281 mm
Supported storage drive interfacesM.2, SATA III
Number of SAS ports2
Ethernet LAN (RJ-45) ports3
VGA (D-Sub) ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
PCI Express x16 slots1
Number of M.2 (M) slots1
Weight520 g
Harmonized System (HS) code84733020
WarningsAdjust adequate ventilation to avoid overheating and potential damage.
