Asus ROG CROSSHAIR X870E HERO AM5 4DDR5 HDMI/USB-C

Asus ROG CROSSHAIR X870E HERO AM5 4DDR5 HDMI/USB-C

Out Of Stock
ID: 167439
Model ROG CROSSHAIR X870E HERO
Barcode 4711387710302
Brand: ASUS
709.31€
(Ex Tax: 572.02€)
Payment options

Delivery options

omniva  venipak



Specification
Description
Specification
artikuls: KBASUAA8X870A02
svītrkods: 4711387710302
Description
SKUKBASUAA8X870A02
Barcode4711387710302
ModelROG CROSSHAIR X870E HERO
CPU socketSocket AM5
Processor familyAMD Ryzen 7
Processor familyAMD Ryzen 3
Processor familyAMD Ryzen 5
Processor familyAMD Ryzen 9
Integrated CPUNo
Chipset manufacturerAMD
Chipset typeAMD X870E
Memory typeDDR5
Number of DDR5 slots4
Memory bus frequency9000 MHz
Memory bus frequency8600 MHz
Memory bus frequency8200 MHz
Memory bus frequency8000 MHz
Memory bus frequency7000 MHz
Max memory size192
Expansion slots5 x M.2
Expansion slots2 x PCIe 5.0 x16
Expansion slots4 x PCIe 4.0 x 16
Max. number of SATA devices4
RAIDYes
Detailed data on disk/drive interfacesSupports 5 x M.2 slots and 1 x SlimSAS connector and 4 x SATA 6Gb/s ports* AMD Ryzen 9000 and 7000 Series Desktop Processors M.2_1 (M-Key) socket, type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_2 (M-Key) socket, type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_3 (M-Key) socket, type 2242/2260/2280 (supports PCIe 5.0 x4 mode) AMD Ryzen 8000 Series Desktop Processors M.2_1 (M-Key) socket, type 2242/2260/2280 (supports PCIe 4.0 mode) x4) M.2_2 (M-Key) Socket, Type 2242/2260/2280 (Not Supported) M.2_3 (M-Key) Socket, Type 2242/2260/2280 (Not Supported) AMD X870E Chipset M.2_4 (M-Key) Socket, Type 2242/2260/2280 (Supports PCIe 4.0 x4 mode) M.2_5 (M-Key) Socket, Type 2280 (Supports PCIe 4.0 x4 mode) SlimSAS Socket Supports PCIe 4.0 x4 mode. 4 x SATA 6Gb/s ports *AMD RAIDXpert2 technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10. RAID 5 is only supported by AMD Ryzen 9000 series processors. ** When M.2_2 and M.2_3 are enabled at the same time, PCIEX16_2 will be disabled. *** When M.2_3 is enabled, PCIEX16_1 will run x8 and PCIEX16_2 will run x4, M.2_2 will be disabled.
Graphics1 x HDMI port* 2 x USB4 (40Gbps) ports support USB Type-C display output** *Supports 4K@60Hz as per HDMI 2.1 specification. **Supports up to 4K@60Hz as per DisplayPort 1.4a specification
Sound cardROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082*- Impedance detection for front and rear headphone outputs- Supports: jack detection, streaming, microphone jack repurposing on the front panel- High-quality stereo playback output SNR 120 dB and recording input SNR 110 dB- Supports up to 32-bit/384 kHz playback on the front panelAudio Features- SupremeFX Shielding Technology- ESS ES9219 QUAD DAC- Gold-plated audio jacks- Rear optical S/PDIF output port- Premium audio capacitors* A chassis with an HD audio module on the front panel is required to support 7.1 Surround Sound audio output.** The LINE OUT port on the rear panel does not support surround sound. If you want to use surround sound, connect an audio output device to the audio jack on the front panel of the case or use a USB audio device.
Network interface1 x 10/100/1000/2500 Mbit/s
Network interface1 x 10/100/1000/2500/5000 Mbit/s
Network interfaceWi-Fi 802.11a/b/g/n/ac/ax/be
Network interfaceBluetooth
Network interfaceWi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6 GHz frequency band** Supports Wi-Fi 7 320 MHz band, up to 6.5 Gbps transfer speed. Bluetooth v5.4*** * Wi-Fi features may vary by OSFor Windows 11, Wi-Fi 7 will require version 24H2 or later for full functionality, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.For Windows 10, please note that there is no driver available, please refer to the Wi-Fi chipset vendor's website for details.** Wi-Fi 6 GHz frequency band and bandwidth regulations may vary by country.***Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB ports at back panel10
USB ports on motherboard10
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports10
FireWire (IEEE 1394)No
COM connector / portNo
LPT connector / portNo
External connectors2 x USB 3.1 Type-C
External connectors1 x HDMI
External connectors1 x Line Out (front)
External connectors1 x MIC (front)
External connectors2 x RJ-45
External connectors1 x S/PDIF
External connectors2 x USB4 Type-C
External connectors1 x Przycisk Clear CMOS
External connectors6 x USB 3.1
External connectors1 x USB BIOS Flashback button
Onboard connectors1 x 4pin CPU fan
Onboard connectors1 x OC PCIe switch
Onboard connectors1 x Thermal sensor connector
Onboard connectors1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors1 x 4pin wentylator OPT CPU
Onboard connectors4 x 4pin Chassis fan
Onboard connectors1 x 4-pin water-pump-fan
Onboard connectors1 x 8pin 12V power
Onboard connectors1 x 24pin ATX zasilanie
Onboard connectors5 x M.2
Onboard connectors4 x SATA III 6Gb/s
Onboard connectors2 x USB 2.0/1.1 header
Onboard connectors2 x USB 3.0 header
Onboard connectors2 x USB C
Onboard connectors1 x Front panel audio header
Onboard connectors1 x ReTry button
Onboard connectors3 x Addressable LED
Onboard connectors1 x Flex Key pin
BIOS256Mb Flash ROM, UEFI AMI BIOS
Form factorATX
Dimensions30.5 cm x 24.4 cm
Accessories includedARGB RGB Extension Cable 4 x SATA 6Gb/s Cables ASUS WiFi Q-Antenna Q-Connector 2 x M.2 Q-Latch Pack 3 x M.2 Q-Slide Pack 5 x M.2 Rubber Pack ROG Stickers ROG Thank You Card ROG Bottle Opener USB Drive with Tools and Drivers Quick Start Guide
Supported operating systemsWindows 11
SoftwareROG Exclusive Software- ROG CPU-Z- Dolby Atmos- Internet Security (1-year full version)- Polymo Lighting IIASUS Exclusive Software- Armoury Crate- AIDA64 Extreme (1-year full version)- Aura Creator- Aura Sync- Fan Xpert 4 (with AI Cooling II)- GameFirst- HWiNFO- Power SavingASUS DriverHubASUS GlideXUSB Wattage WatcherTurboV CoreWinRAR (40-day free trial)Adobe Creative Cloud (free trial)UEFI BIOSAI Overclocking GuideASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ Mode- ASUS MyHotkeyFlexKey
DesignationCE+WEEE
