Gigabyte B760 GAMING X GEN5 Motherboard - Supports 14th Gen. Intel Core CPUs, 8+1+1 phases VRM, up to 5600MHz DDR5, 3xPCIe 4.0 M.2, 2.5 GbE LAN, USB 3.2 Gen 2

GIGABYTE

Gigabyte B760 GAMING X GEN5 Motherboard - Supports 14th Gen. Intel Core CPUs, 8+1+1 phases VRM, up to 5600MHz DDR5, 3xPCIe 4.0 M.2, 2.5 GbE LAN, USB 3.2 Gen 2

Delivery to the store in 5 to 7 business days.
ID: 181277
Model B760 GAMING X GEN5
Barcode 4719331872120
136.32€
(Ex Tax: 109.94€)
Payment options

Delivery options

omniva  venipak



Description
Description
Compatible processor seriesIntel Core i7 12th Gen
Processor manufacturerIntel
Processor socketLGA 1700
Supported processor socketsLGA 1700
HDCPYes
Maximum resolution4096 x 2304 pixels
Motherboard form factorATX
Audio output channels7.1 channels
PC health monitoringTemperature
Windows operating systems supportedWindows 11 x64
Motherboard chipset familyIntel
Power source typeATX
Motherboard chipsetIntel B760
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR5-SDRAM
Memory channelsDual-channel
Supported memory clock speed (max)7600 MHz
Unbuffered memoryYes
Supported memory clock speeds5600
Maximum internal memory256 GB
Maximum internal memory per slot64 GB
ECC сompatibilityECC & Non-ECC
Depth244 mm
Width305 mm
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
TPM connectorYes
Number of CPU fan connectors2
12V power connectorYes
Number of RGB LED pin headers4
Number of water pump connectors2
RGB LED pin headerYes
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
Number of EPS power connectors (8-pin)1
Number of SATA III connectors4
USB 2.0 connectors2
ATX Power connector (24-pin)Yes
EPS power connector (8-pin)Yes
Front panel connectorYes
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of chassis fan connectors4
CPU fan connectorYes
Front panel audio connectorYes
S/PDIF out connectorYes
Clear CMOS jumperYes
Desktop Management Interface (DMI) version2.7
BIOS typeUEFI AMI
Number of storage drives supported7
Number of HDDs supported4
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, PCI Express 4.0, SATA III
RAID supportYes
RAID levels10
HDMI version2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
HDMI ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
DisplayPorts quantity1
USB 2.0 ports quantity5
DisplayPort version1.2
Ethernet LAN (RJ-45) ports1
1st M.2 highest PCI Express generation4.0
2nd M.2 largest key size22110
2nd M.2 highest PCI Express generation4.0
1st M.2 largest key size22110
PCI Express x16 (Gen 5.x) slots1
PCI Express x16 (Gen 3.x) slots2
Number of M.2 (M) slots3
3rd M.2 largest key size22110
3rd M.2 highest PCI Express generation4.0
