Home Computers and equipment Computer components Motherboard Gigabyte Motherboard H610M S2H V2 s1700 2DDR 5 DP/HDMI/DSUB M.2 mATX
Gigabyte Motherboard H610M S2H V2 s1700 2DDR 5 DP/HDMI/DSUB M.2 mATX

GIGABYTE

Gigabyte Motherboard H610M S2H V2 s1700 2DDR 5 DP/HDMI/DSUB M.2 mATX

Delivery to the store in 5 to 7 business days.
ID: 164234
Model H610M S2H V2
Barcode 4719331859817
66.31€
(Ex Tax: 53.48€)
Payment options

Delivery options

omniva  venipak



Specification
Description
Specification
artikuls: KBGBAIIEH610U06
svītrkods: 4719331859817
Description
SKUKBGBAIIEH610U06
Barcode4719331859817
ModelH610M S2H V2
CPU socketLGA1700
Processor familyIntel Pentium Gold
Processor familyIntel Celeron
Processor familyIntel Core i3
Processor familyIntel Core i5
Processor familyIntel Core i7
Processor familyIntel Core i9
GenerationTwelve
GenerationFourteenth
GenerationThirteenth
Integrated CPUNo
Chipset manufacturerIntel
Chipset typeIntel H610 Express
Memory typeDDR5
Number of DDR5 slots2
Memory bus frequency4400 MHz
Memory bus frequency4800 MHz
Memory bus frequency5200 MHz
Memory bus frequency5600 MHz
Max memory size128
Expansion slots1 x PCIe 4.0 x 16
Expansion slots1 x PCIe 3.0 x 1
Max. number of SATA devices4
RAIDNo
Detailed data on disk/drive interfaces1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors
GraphicsIntegrated Graphics Processor - Intel HD Graphics support 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz (Support for HDMI 2.1 version and HDCP 2.3.; Support native HDMI 2.1 TMDS compatible ports.) 2 x DisplayPorts, supporting a maximum resolution of 4096x2304@60 Hz (Support for DisplayPort 1.2 version and HDCP 2.3.)
Sound cardRealtek audio codec High Definition Audio support Audio channels: 2 / 4 / 5.1 / 7.1
Network interface1 x 10/100/1000 Mbit/s
Network interfaceRealtek GbE LAN chip (1 Gbps/100 Gbps/10 Mbps)
USB ports at back panel6
USB ports on motherboard6
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports4
FireWire (IEEE 1394)No
COM connector / portYes
LPT connector / portNo
External connectors1 x PS/2 Keyboard/MouseCombo
External connectors2 x USB 3.2 Gen 1 Type-A
External connectors1 x D-Sub
External connectors2 x DisplayPort
External connectors1 x HDMI
External connectors1 x Line In
External connectors1 x Line Out
External connectors1 x MIC
External connectors4 x USB 2.0
External connectors1 x RJ-45
Onboard connectors1 x RGB LED strip header
Onboard connectors1 x Clear CMOS jumper
Onboard connectors1 x Chassis intrusion header
Onboard connectors1 x TPM header
Onboard connectors1 x System panel header
Onboard connectors1 x Front panel audio header
Onboard connectors1 x Serial port header
Onboard connectors2 x USB 3.2 Gen 1 Type-A
Onboard connectors4 x USB 2.0/1.1
Onboard connectors1 x 4pin CPU fan
Onboard connectors2 x 4pin Chassis fan
Onboard connectors1 x 8pin 12V power
Onboard connectors1 x 24pin ATX zasilanie
Onboard connectors1 x M.2
Onboard connectors4 x SATA III 6Gb/s
BIOS1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form factormicro ATX
Dimensions22.3 x 19.6 cm
Supported operating systemsWindows 10
Supported operating systemsWindows 11
SoftwareNorton Internet Security (wersja OEM) LAN bandwidth management software
DesignationCE+WEEE
