Chieftec Vega PPG-1000-C power supply unit 1000 W 24-pin ATX ATX White

Chieftec Vega PPG-1000-C power supply unit 1000 W 24-pin ATX ATX White

Delivery to the store takes 3 - 7 business days.
ID: 123685
Model PPG-1000-C
Barcode 0753263079091
Brand: CHIEFTEC
106.26€
(Ex Tax: 85.70€)
Payment options

Delivery options

omniva  venipak



Description
Description
Cooling typeActive
Product colourWhite
Fan diameter13.5 cm
IlluminationNo
Combined power (-12V)3.6 W
AC input frequency50/60 Hz
Power protection featuresSurge and inrush
Max output current (-12V)0.3 A
Max output current (+3.3V)20 A
Combined power (+12V)1000 W
AC input voltage100 - 240 V
Max output current (+5V)20 A
Input current12 A
Combined power (+5V)100 W
Combined power (+3.3V)100 W
Combined power (+5Vsb)15 W
Max output current (+12V)83.33 A
Max output current (+5Vsb)3 A
Total power1000 W
Height85 mm
Width150 mm
Depth150 mm
PurposePC
Power supply unit (PSU) form factorATX
Bearing technologyFDB
80 PLUS certification80 PLUS Gold
ATX version3.1
CPU power cable length65 cm
Peripheral (Molex) power cable length150 mm
PCI Express power cable length60 cm
Motherboard power cable length60 cm
PCI Express connectorYes
CPU power connector (4+4 pin)Yes
Number of SATA power connectors6
SATA power cable length400 mm
ATX Power connector (24-pin)Yes
Motherboard power connector24-pin ATX
Peripheral (Molex) power connectors (4-pin)3
PCI Express power connectors (6+2 pin)4
EPS power connector (8-pin)Yes
Cabling typeFully-Modular
Number of EPS connectors2
PCI Express power connectors (12+4 pin)1
EPS power connector (4+4 pin)Yes
PCI Express power connectors (12+4 pin) cable length600 mm
