Gigabyte UD850GM 850W PG5 V2 (GP-UD850GM PG5 V2) - power supply, black

GIGABYTE

Gigabyte UD850GM 850W PG5 V2 (GP-UD850GM PG5 V2) - power supply, black

Delivery to the store takes 3 - 7 business days.
ID: 105071
Model GP-UD850GM PG5 V2
Barcode 4719331555993
94.06€
(Ex Tax: 75.85€)
Payment options

Delivery options

omniva  venipak



Description
Description
Cooling typeActive
Fan diameter12 cm
Product colourBlack
On/off switchYes
Number of fans1 fan(s)
Power protection featuresOver power
Combined power (+5V)105 W
Max output current (+3.3V)20 A
Power factor0.9
Max output current (+12V)70.8 A
Combined power (+5Vsb)15 W
Combined power (+3.3V)105 W
AC input frequency50/60 Hz
Combined power (+12V)850 W
Input current12 - 6 A
Efficiency90%
Max output current (+5V)20 A
Hold time16 ms
AC input voltage100 - 240 V
Power Factor Correction (PFC) typeActive
Combined power (-12V)3.6 W
Total power850 W
Max output current (+5Vsb)3 A
Max output current (-12V)0.3 A
Width150 mm
Height86 mm
Depth140 mm
Weight2.4 kg
PurposePC
Bearing technologyHYB
Mean time between failures (MTBF)100000 h
Power supply unit (PSU) form factorATX
ATX version3.1
80 PLUS certification80 PLUS Gold
Package weight2.56 kg
Package width618 mm
Package typeBox
Package height211 mm
Package depth269 mm
PCI Express connectorYes
CPU power cable length60 cm
SATA power cable length150
Cabling typeFully-Modular
Floppy drive power connector1
PCI Express power connectors (16-pin)1
Number of SATA power connectors8
PCI Express power connectors (6+2 pin)4
Peripheral (Molex) power cable length500 mm
Motherboard power connector20+4 pin ATX
Motherboard power cable length61 cm
Number of EPS connectors2
Peripheral (Molex) power connectors (4-pin)3
PCI Express power cable length70 cm
CPU power connector (4+4 pin)Yes
Warranty period10 year(s)
