Uni-T UT262E Non-Contact Phase Sequence Detector

Uni-T UT262E Non-Contact Phase Sequence Detector

Delivery to the store in 5 to 7 business days.
ID: 211315
Model UT262E
Barcode 6935750526255
Brand: UNI-T
93.90€
(Ex Tax: 75.73€)
Payment options

Delivery options

omniva  venipak



Description
Description

Uni-T UT262E Non-Contact Phase Sequence Detector

The UT262E is a non-contact phase detector in a clamp-on design, engineered for safe operation on three-phase systems without the need to touch exposed wires. This reduces the risk of electrical arcing and minimizes the danger of electric shock during field work. The device allows for quick verification of phase presence, identification of phase sequence, detection of phase loss, and localization of wire breaks, utilizing both audible and visual signals. It is ideal for service work, motor installation, and electrical system maintenance.

Included

  • Phase sequence detector
  • AA batteries x2
  • Carrying case
  • User manual
  • Warranty card
  • Inspection certificate



Specifications

ManufacturerUni-T
ModelUT262E
TypeNon-contact phase sequence detector
Measurement methodNon-contact (inductive clamps)
Voltage range70~1000V AC
Operating frequency45~66 Hz
FunctionsPhase detection / phase loss / phase sequence / open circuit detection
Cable diameterØ2~40 mm
Cable length0.6 m
SignalingLED + buzzer
Signal volume65~70 dB
Auto power offAfter approximately 5 minutes
Operating timeOver 20 hours
Safety classCAT III 1000V / CAT IV 600V
Protection ratingIP52
Power supply2 × AA 1.5V
Weight237.7 g (with batteries)
Dimensions88 × 30 × 66 mm
CertificationsCE, UKCA
